CED( Flute Diameter) | CEL( Cutting Length) | SHK( Shank Diameter) | OVL( Total Length) |
3.175 | 12 | 3.175 | 38 |
3.175 | 15 | 3.175 | 38 |
3.175 | 17 | 3.175 | 45 |
3.175 | 22 | 3.175 | 50 |
4 | 17 | 4 | 45 |
4 | 22 | 4 | 50 |
4 | 25 | 4 | 55 |
4 | 32 | 4 | 70 |
5 | 17 | 5 | 50 |
5 | 22 | 5 | 50 |
6 | 17 | 6 | 50 |
6 | 22 | 6 | 50 |
6 | 25 | 6 | 55 |
6 | 32 | 6 | 70 |
8 | 22 | 8 | 60 |
8 | 25 | 8 | 60 |
8 | 32 | 8 | 70 |
8 | 45 | 8 | 80 |
10 | 35 | 10 | 75 |
10 | 45 | 10 | 90 |
10 | 52 | 10 | 100 |
12 | 35 | 12 | 80 |
12 | 52 | 12 | 100 |
item | value |
Warranty | Other |
Customized support | OEM, ODM |
Place of Origin | China |
Shandong | |
Brand Name | yingba |
Model Number | xfh3-12 |
Material | Carbide |
Coating | AlTiN |
Flute | 2Flutes |
Usage | CNC Machine Center |
HRC | 45/50/60/70 Degrees |
Product Name | 2F Compression Bit |
